RECOM RS系列DC/DC轉換器:RS-0512S,RS-1209S,RS-2405S,RS-4812S,RS-123.3S
發布時間：2025-10-28 09:14:41 瀏覽：264
RS系列是RECOM Power推出的高可靠性、緊湊型隔離式DC/DC轉換器，專為工業級應用設計。該系列提供2W功率輸出，采用SIP8封裝(UL94
V-0阻燃材料)，支持單路或雙路穩壓輸出，適用于嚴苛環境下的各類電子設備供電需求。
核心特性
?、?工業級設計
寬工作溫度范圍：-40°C ~ +100°C(需降額)，適應極端環境。
高功率密度：緊湊的SIP8封裝(21.8mm×9.2mm×11.1mm)，節省PCB空間。
連續短路保護(SCP)：自動恢復功能，提升系統可靠性。
?、?靈活的輸入/輸出配置
輸入電壓范圍：
標準版(2:1)：4.5-9V、9-18V、18-36V、36-72V。
Z版(4:1)：9-36V、18-72V，兼容5V/12V供電系統。
輸出電壓選項：
單路：3.3V/5V/9V/12V/15V。
雙路：±3.3V/±5V/±9V/±12V/±15V。
?、?高隔離性能
可選隔離電壓：
標準版：1kVDC(500VAC)。
/H2選項：2kVDC(1kVAC)。
/H3選項：3kVDC(1.5kVAC)。
低噪聲設計：無需外接電容，簡化電路布局。
?、?智能控制功能
遠程開關控制(ON/OFF CTRL)：
開啟：CTRL引腳懸空或高阻。
關閉：CTRL接高電平(5~12V，需串聯保護電路)。
典型應用場景
工業自動化：PLC、傳感器、電機控制。
醫療設備：符合EN 60601-1標準，適用于便攜式儀器。
通信基礎設施：基站、光纖設備(支持寬輸入電壓)。
交通運輸：車載電子、軌道交通(寬溫設計)。
選型指南：
| 產品編號 | 功率（W） | 輸入電壓 （V） | 主輸出電壓（V） | 安裝類型 |
| RS-0505D | 2 | 4.50-9.0 | ± 5 | THT |
| RS-0505D/H2 | 2 | 4.50-9.0 | ± 5 | THT |
| RS-0505D/H3 | 2 | 4.50-9.0 | ± 5 | THT |
| RS-0505S | 2 | 4.50-9.0 | 5 | THT |
| RS-0505S/H2 | 2 | 4.50-9.0 | 5 | THT |
| RS-0505S/H3 | 2 | 4.50-9.0 | 5 | THT |
| RS-0509D | 2 | 4.50-9.0 | ± 9 | THT |
| RS-0509D/H2 | 2 | 4.50-9.0 | ± 9 | THT |
| RS-0509D/H3 | 2 | 4.50-9.0 | ± 9 | THT |
| RS-0509S | 2 | 4.50-9.0 | 9 | THT |
| RS-0509S/H2 | 2 | 4.50-9.0 | 9 | THT |
| RS-0509S/H3 | 2 | 4.50-9.0 | 9 | THT |
| RS-0512D | 2 | 4.50-9.0 | ± 12 | THT |
| RS-0512D/H2 | 2 | 4.50-9.0 | ± 12 | THT |
| RS-0512D/H3 | 2 | 4.50-9.0 | ± 12 | THT |
| RS-0512S | 2 | 4.50-9.0 | 12 | THT |
| RS-0512S/H2 | 2 | 4.50-9.0 | 12 | THT |
| RS-0512S/H3 | 2 | 4.50-9.0 | 12 | THT |
| RS-0515D | 2 | 4.50-9.0 | ± 15 | THT |
| RS-0515D/H2 | 2 | 4.50-9.0 | ± 15 | THT |
| RS-0515D/H3 | 2 | 4.50-9.0 | ± 15 | THT |
| RS-0515S | 2 | 4.50-9.0 | 15 | THT |
| RS-0515S/H2 | 2 | 4.50-9.0 | 15 | THT |
| RS-0515S/H3 | 2 | 4.50-9.0 | 15 | THT |
| RS-053.3D | 2 | 4.50-9.0 | ± 3.3 | THT |
| RS-053.3D/H2 | 2 | 4.50-9.0 | ± 3.3 | THT |
| RS-053.3D/H3 | 2 | 4.50-9.0 | ± 3.3 | THT |
| RS-053.3S | 2 | 4.50-9.0 | 3.3 | THT |
| RS-053.3S/H2 | 2 | 4.50-9.0 | 3.3 | THT |
| RS-053.3S/H3 | 2 | 4.50-9.0 | 3.3 | THT |
| RS-1205D | 2 | 9.0-18.0 | ± 5 | THT |
| RS-1205D/H2 | 2 | 9.0-18.0 | ± 5 | THT |
| RS-1205D/H3 | 2 | 9.0-18.0 | ± 5 | THT |
| RS-1205S | 2 | 9.0-18.0 | 5 | THT |
| RS-1205S/H2 | 2 | 9.0-18.0 | 5 | THT |
| RS-1205S/H3 | 2 | 9.0-18.0 | 5 | THT |
| RS-1209D | 2 | 9.0-18.0 | ± 9 | THT |
| RS-1209D/H2 | 2 | 9.0-18.0 | ± 9 | THT |
| RS-1209D/H3 | 2 | 9.0-18.0 | ± 9 | THT |
| RS-1209S | 2 | 9.0-18.0 | 9 | THT |
| RS-1209S/H2 | 2 | 9.0-18.0 | 9 | THT |
| RS-1209S/H3 | 2 | 9.0-18.0 | 9 | THT |
| RS-1212D | 2 | 9.0-18.0 | ± 12 | THT |
| RS-1212D/H2 | 2 | 9.0-18.0 | ± 12 | THT |
| RS-1212D/H3 | 2 | 9.0-18.0 | ± 12 | THT |
| RS-1212S | 2 | 9.0-18.0 | 12 | THT |
| RS-1212S/H2 | 2 | 9.0-18.0 | 12 | THT |
| RS-1212S/H3 | 2 | 9.0-18.0 | 12 | THT |
| RS-1215D | 2 | 9.0-18.0 | ± 15 | THT |
| RS-1215D/H2 | 2 | 9.0-18.0 | ± 15 | THT |
| RS-1215D/H3 | 2 | 9.0-18.0 | ± 15 | THT |
| RS-1215S | 2 | 9.0-18.0 | 15 | THT |
| RS-1215S/H2 | 2 | 9.0-18.0 | 15 | THT |
| RS-1215S/H3 | 2 | 9.0-18.0 | 15 | THT |
| RS-123.3D | 2 | 9.0-18.0 | ± 3.3 | THT |
| RS-123.3D/H2 | 2 | 9.0-18.0 | ± 3.3 | THT |
| RS-123.3D/H3 | 2 | 9.0-18.0 | ± 3.3 | THT |
| RS-123.3S | 2 | 9.0-18.0 | 3.3 | THT |
| RS-123.3S/H2 | 2 | 9.0-18.0 | 3.3 | THT |
| RS-123.3S/H3 | 2 | 9.0-18.0 | 3.3 | THT |
| RS-2405D | 2 | 18.0-36.0 | ± 5 | THT |
| RS-2405D/H2 | 2 | 18.0-36.0 | ± 5 | THT |
| RS-2405D/H3 | 2 | 18.0-36.0 | ± 5 | THT |
| RS-2405S | 2 | 18.0-36.0 | 5 | THT |
| RS-2405S/H2 | 2 | 18.0-36.0 | 5 | THT |
| RS-2405S/H3 | 2 | 18.0-36.0 | 5 | THT |
| RS-2409D | 2 | 18.0-36.0 | ± 9 | THT |
| RS-2409D/H2 | 2 | 18.0-36.0 | ± 9 | THT |
| RS-2409D/H3 | 2 | 18.0-36.0 | ± 9 | THT |
| RS-2409S | 2 | 18.0-36.0 | 9 | THT |
| RS-2409S/H2 | 2 | 18.0-36.0 | 9 | THT |
| RS-2409S/H3 | 2 | 18.0-36.0 | 9 | THT |
| RS-2412D | 2 | 18.0-36.0 | ± 12 | THT |
| RS-2412D/H2 | 2 | 18.0-36.0 | ± 12 | THT |
| RS-2412D/H3 | 2 | 18.0-36.0 | ± 12 | THT |
| RS-2412S | 2 | 18.0-36.0 | 12 | THT |
| RS-2412S/H2 | 2 | 18.0-36.0 | 12 | THT |
| RS-2412S/H3 | 2 | 18.0-36.0 | 12 | THT |
| RS-2415D | 2 | 18.0-36.0 | ± 15 | THT |
| RS-2415D/H2 | 2 | 18.0-36.0 | ± 15 | THT |
| RS-2415D/H3 | 2 | 18.0-36.0 | ± 15 | THT |
| RS-2415S | 2 | 18.0-36.0 | 15 | THT |
| RS-2415S/H2 | 2 | 18.0-36.0 | 15 | THT |
| RS-2415S/H3 | 2 | 18.0-36.0 | 15 | THT |
| RS-243.3D | 2 | 18.0-36.0 | ± 3.3 | THT |
| RS-243.3D/H2 | 2 | 18.0-36.0 | ± 3.3 | THT |
| RS-243.3D/H3 | 2 | 18.0-36.0 | ± 3.3 | THT |
| RS-243.3S | 2 | 18.0-36.0 | 3.3 | THT |
| RS-243.3S/H2 | 2 | 18.0-36.0 | 3.3 | THT |
| RS-243.3S/H3 | 2 | 18.0-36.0 | 3.3 | THT |
| RS-4805D | 2 | 36.0-72.0 | ± 5 | THT |
| RS-4805D/H2 | 2 | 36.0-72.0 | ± 5 | THT |
| RS-4805D/H3 | 2 | 36.0-72.0 | ± 5 | THT |
| RS-4805S | 2 | 36.0-72.0 | 5 | THT |
| RS-4805S/H2 | 2 | 36.0-72.0 | 5 | THT |
| RS-4805S/H3 | 2 | 36.0-72.0 | 5 | THT |
| RS-4809D | 2 | 36.0-72.0 | ± 9 | THT |
| RS-4809D/H2 | 2 | 36.0-72.0 | ± 9 | THT |
| RS-4809D/H3 | 2 | 36.0-72.0 | ± 9 | THT |
| RS-4809S | 2 | 36.0-72.0 | 9 | THT |
| RS-4809S/H2 | 2 | 36.0-72.0 | 9 | THT |
| RS-4809S/H3 | 2 | 36.0-72.0 | 9 | THT |
| RS-4812D | 2 | 36.0-72.0 | ± 12 | THT |
| RS-4812D/H2 | 2 | 36.0-72.0 | ± 12 | THT |
| RS-4812D/H3 | 2 | 36.0-72.0 | ± 12 | THT |
| RS-4812S | 2 | 36.0-72.0 | 12 | THT |
| RS-4812S/H2 | 2 | 36.0-72.0 | 12 | THT |
| RS-4812S/H3 | 2 | 36.0-72.0 | 12 | THT |
| RS-4815D | 2 | 36.0-72.0 | ± 15 | THT |
| RS-4815D/H2 | 2 | 36.0-72.0 | ± 15 | THT |
| RS-4815D/H3 | 2 | 36.0-72.0 | ± 15 | THT |
| RS-4815S | 2 | 36.0-72.0 | 15 | THT |
| RS-4815S/H2 | 2 | 36.0-72.0 | 15 | THT |
| RS-4815S/H3 | 2 | 36.0-72.0 | 15 | THT |
| RS-483.3D | 2 | 36.0-72.0 | ± 3.3 | THT |
| RS-483.3D/H2 | 2 | 36.0-72.0 | ± 3.3 | THT |
| RS-483.3D/H3 | 2 | 36.0-72.0 | ± 3.3 | THT |
| RS-483.3S | 2 | 36.0-72.0 | 3.3 | THT |
| RS-483.3S/H2 | 2 | 36.0-72.0 | 3.3 | THT |
| RS-483.3S/H3 | 2 | 36.0-72.0 | 3.3 | THT |
深圳市立維創展科技有限公司，專注于RECOM電源模塊產品，并提供替代產品，詳情可咨詢立維創展。
